09/2007
2-41
Phaser 8860/8860MFP Service Manual
36,001.67, 36,002.44
Error Messages and Codes
Initial Issue
36,001.67 Drum Maintenance Drive Faults
An error occurred while attempting to position the Drum Maintenance Kit. The following trou-
bleshooting procedure applies to this error:
Initial Actions
• Check for ink spills or obstructions near the Drum Maintenance Kit.
• Check for obstructions or damage to the Pivot Plate and Cam Rollers.
• If the problem persists, follow the procedure below.
Primary Causes
The troubleshooting table lists parts and wiring referenced in the troubleshooting procedure.
Troubleshooting Procedure
36,002.44 Drum Maintenance Kit Fault
An error occurred while attempting to position the Drum Maintenance Kit. The following trou-
bleshooting procedure applies to this error:
Initial Actions
• Check for ink spills or obstructions near the Drum Maintenance Kit.
• Check for obstructions or damage to the Pivot Plate and Cam Rollers.
• If the problem persists, follow the procedure below.
Primary Causes
The troubleshooting table lists parts and wiring referenced in the troubleshooting procedure.
Troubleshooting Procedure
Drum Maintenance Drive Faults
36,001.67 An error occurred while attempting to position the Drum Maintenance Kit.
Table 1 36,001.67 Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
Drum Maintenance Kit PL 1.0
Drum Maintenance Pivot Plate PL 2.0 I/O Board (2/2) - Figure 12
Table 2 Drum Maintenance Drive Faults 36,001.67 Troubleshooting Procedure
Step Questions or Actions Yes No
1 Check that system grounds are in place.
Are the grounds secure and undamaged?
Go to Step 2. Repair or replace the
grounds.
2 Test Drum Maintenance operation.
Run the Service Diagnostics Drum Main-
tenance/Transfix Home test.
Does the system operate correctly?
Go to Step 3. Replace the Pro-
cess Drive (REP
4.0.7).
3 Test the Drum Maintenance drive.
Run the Service Diagnostics Drum Main-
tenance Drive test.
Does the drive operate correctly?
Replace the Drum
Maintenance Pivot
Plate and Shaft
(REP 2.0.16).
Replace the Pro-
cess Drive (REP
4.0.7)
Drum Maintenance Drive Faults
36,002.44 The system can not write to the Drum Maintenance Kit.
Table 1 36,001.67 Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
Drum Maintenance Kit PL 1.0
Drum Maintenance Pivot Plate PL 2.0 I/O Board (2/2) - Figure 12
Table 2 Drum Maintenance Drive Faults 36,001.67 Troubleshooting Procedure
Step Questions or Actions Yes No
1 Check that the Drum Maintenance Kit is
correctly installed.
Is the installation correct?
Go to Step 2. Correct and retest.
2 Replace the Drum Maintenance Kit
Does the error persist?
Replace the Drum
Maintenance Pivot
Plate and Shaft
(REP 2.0.16).
Complete.
