09/2007
xviii
Phaser 8860/8860MFP Service Manual
Parts of the 8860
Initial Issue
Introduction
Parts of the 8860
Front View
Figure 1 8570MFP Front View
1. Tray 4 (optional)
2. Tray 3 (optional)
3. Tray 2
4. Tray 1 (MPT)
5. Control Panel
6. Exit Cover Release
7. Front Door Release
8. Exit Cover
9. Ink Loader
10. Output Tray Extension
11. Interface Cover
12. Side Door
Side View with Interface Connections
Figure 2 Side View with Interface Connections
1. Drum Maintenance Kit
2. Waste Tray
3. AC Power Cord Connection
4. Power Switch
5. USB Connection
6. Configuration Card
7. Ethernet Connection
Back View - Electronics Module
The system’s main electronics and power supply are enclosed in a metal case called the Elec-
tronics Module. The rear panel allows access to the electronics module, RAM, and NVRAM
chips. The system’s Hard Drive, if installed, is mounted on the rear panel.
NOTE: When replacing the electronics module, transfer these components to the new module.
•RAM
• Configuration Card
• NVRAM Device
• Hard Drive or Flash Disk
