Yamaha F75F - Clamp Bracket Dimensions

Clamp bracket dimensions
1-3
Clamp bracket dimensions
The dimension values may include reference values.
125.4 (4.9)
180 (7.1)180 (7.1)
163.5 (6.4) 163.5 (6.4)
82 (3.2)
20 (0.8)
13 (0.5)
125.4 (4.9)
101.5 (4.0) 101.5 (4.0)
13 (0.5) 13 (0.5)
18.5 (0.7) 50.8 (2.0)
357.2 (14.1)17.5 (0.8)
mm (in)
55.5 (2.2) 254 (10.0)
