A-4
Starting system
Model F75FEHT F75FET F100GEHT F100GET
Starter motor
Type Sliding gear
Output 1.40 kW
Cranking time limit 30 sec
Standard brush length 15.5 mm (0.61 in)
Wear limit 9.5 mm (0.37 in)
Standard commutator
diameter
29.0 mm (1.14 in)
Wear limit 28.0 mm (1.10 in)
Standard commutator
undercut
0.7 mm (0.03 in)
Wear limit 0.2 mm (0.01 in)
Fuel system technical data
Fuel system
Fuel line
Fuel pressure at engine
start switch to “ON”
within 5 seconds
310 kPa (3.1 kgf/cm², 45.0 psi)
Fuel pressure at idle
speed
320 kPa (3.2 kgf/cm², 46.4 psi)
Primer pump
Positive pressure 166.7 kPa (1.67 kgf/cm², 24.2 psi)
166.7 kPa (1.67
kgf/cm², 24.2
psi) (CRB, CHN,
NME, OTH)
179.5 kPa (1.80
kgf/cm², 26.0
psi) (CRB(EPA))
Fuel strainer
Holding pressure (posi-
tive pressure)
200.0 kPa (2.00 kgf/cm², 29.0 psi)
Fuel filter assembly
Fuel inlet holding pres-
sure (positive pressure)
200 kPa (2.00 kgf/cm², 29.0 psi)
Fuel outlet holding pres-
sure (negative pressure)
80 kPa (0.80 kgf/cm², 11.6 psi)
Model F75FEHT F75FET F100GEHT F100GET
Fuel pump
Fuel inlet holding pres-
sure (positive pressure)
196.0 kPa (1.96 kgf/cm², 28.4 psi)
Fuel outlet holding pres-
sure (positive pressure)
196.0 kPa (1.96 kgf/cm², 28.4 psi)
Vapor separator tank
Float height 50.5 mm (1.99 in)
Canister
Holding pressure (posi-
tive pressure)
19.6 kPa (0.20 kgf/cm², 2.8 psi)
Power unit technical data
Power unit
Compression pressure
Minimum (reference
data)
854.0 kPa (8.54 kgf/cm², 123.8 psi)
Engine oil
Engine oil pressure at
idle speed (reference
data)
470.0 kPa (4.70 kgf/cm², 68.2 psi)
Engine oil pressure at
3000 r/min (reference
data)
580.0 kPa (5.80 kgf/cm², 84.1 psi)
* For the checking method, see “Checking the oil pressure” (7-1). The figures are for reference only.
Thermostat
Valve opening tempera-
ture
58–62 °C (136–144 °F)
Fully open temperature 70 °C (158 °F)
Fully open stroke 4.3 mm (0.17 in)
Timing belt
Installation height 0.7 mm (0.03 in)
