Model
F75FEHT F75FET F100GEHT F100GET
Output peak voltage at
cranking (loaded) (refer-
ence data)
9.0 V
Output peak voltage at
1500 r/min (loaded) (ref-
erence data)
26.8 V
Output peak voltage at
3500 r/min (loaded) (ref-
erence data)
31.6 V
Intake air pressure/temperature sensor
Input voltage 5 V
Thermo sensor
Resistance at 75 °C (167
°F)
0.360–0.383 k
Shift position switch
Input voltage 5 V
Knock sensor
Resistance
504–616 k
Fuel injection control system
Water detection switch
Input voltage 12 V
Fuel injector
Input voltage 12 V
Resistance (reference
data)
12.20 
High-pressure fuel pump
Input voltage 12 V
Resistance (reference
data)
0.7 
ISC valve
Resistance
27.0–33.0 
Vapor shut-off valve
Input voltage 12 V
Resistance
30.0–34.0 
Engine speed control system
Model F75FEHT F75FET F100GEHT F100GET
TPS
Output voltage at throttle
valve fully closed
0.58 V
Throttle valve opening
angle at throttle valve
fully closed (reference
data)
0.0°
Input voltage 5 V
Oil pressure switch
Working pressure 127.50–166.70 kPa (1.275–1.667 kgf/cm², 18.49–24.17 psi)
PTT system
Trim sensor
Free position resistance
239–379 
Setting resistance
9–11 
Charging system
Lighting coil
Output peak voltage at
cranking (unloaded) (ref-
erence data)
11.1 V
Output peak voltage at
1500 r/min (unloaded)
(reference data)
40.7 V
Output peak voltage at
3500 r/min (unloaded)
(reference data)
93.7 V
Resistance (reference
data)
0.2 
Rectifier/Regulator
Output voltage at 1500
r/min (loaded) (reference
data)
13 V
Output voltage at 3500
r/min (loaded) (reference
data)
13 V
