b. Connect the tilt limiter couplers “a” and
“b”.
Battery installation
Make sure to connect the battery properly
and select the proper cable sizes. Other
-
wise, a fire could result.
Do not reverse the battery connections.
Otherwise, the charging system could be
damaged.
Rigging recommendation
Battery cable length
The battery cable length from the negative ter-
minal of the battery cable to the rigging grom-
met.
The positive battery cable is 100 mm (3.9 in)
longer than the negative battery cable.
See “Specification” (A-1).
S
L
a
b
b
