2 Installation and Commissioning, IRC5
2.5.15. Connecting a Limit switch override push button
3HAC021313-001 Revision: K84
© Copyright 2004-2008 ABB. All rights reserved.
4. Route the wires together with the existing
harness on the left wall.
xx0500002557
• A: Contact blocks
•B: Wires
• C: Connector X23
5. Fit the connector to the X23 connector on
the contactor interface board.
xx0500002087
Action Note/illustration
Continued
Continues on next page
