Agilent Technologies 5DX Service Guide

5-44 Panel Handling Subsystem
Digital I/O Assembly 5DX Series 3
Input Direct Current Relays
The Input Direct Current Relays handle the input signals from the sensors in the
Panel Handling Subsystem Assemblies and SMEMA inputs from other process
equipment. These inputs are converted to a digital zero or one and passed onto the
System Controller for processing.
There are light emitting diode (LED) indicators positioned at the front of the
Digital I/O Assembly that indicate the status of the various inputs. When the LED
is lit, then the condition associated with the LED is true. Refer to Table 5-7 for a
listing of the Input Direct Current Relay assignments.
Table 5-7: Input Direct Current Relay Assignments
Description of
Input
Hardware Status and
Control
LED ON
Indicates
LED OFF
Indicates
Digit
al I/O
Bit
Left Outer
Barrier Closed
Panel Transport: Left
Outer Barrier is
Closed/Open
The barrier is
closed.
The barrier is
not closed.
28
Left PIP Switch
Engaged
Panel Transport: Left
Front Panel In Place Yes
or No
There is a
panel in
inspection
position.
There is no
panel in
inspection
position.
29
Right Outer
Barrier Closed
Panel Transport: Right
Outer Barrier is
Closed/Open
The barrier is
closed.
The barrier is
not closed.
32
Left Outer
Barrier Clear
Panel Transport: Left
Clear/Blocked Panel
Optical Sensor
The sensor is
clear.
The sensor is
blocked.
33
Right PIP Switch
Engaged
Panel Transport: Right
Front Panel In Place
Yes/No
There is a
panel in
inspection
position.
There is no
panel in
inspection
position.
34
Rear SMEMA
TRI
-- The
downstream
equipment is
ready to
accept a
panel from
the 5DX.
The
downstream
equipment is
not ready to
accept a
panel from
the 5DX.
35
