6-12 Pneumatic Subsystem
Pneumatic Subsystem Components 5DX Series 3
The Outer Barriers can be activated from the Hardware Status and Control output
bits as indicated in Table 6-2.
Table 6-2: Activating the Commands or Output Bits
Output Bit Description Output Bit Number
Close Inner Barrier 09
Left Outer Barrier Open 10
Left Panel-In-Place Stop Retract 11
Right Outer Barrier Open 12
Right Panel-In-Place Stop Retract 13
Caution System Damage may occur if pneumatic pressure is removed from the Agilent
5DX System and the XYZ Stage Assembly is moved manually when not at the
Z-down position. When pneumatic pressure is removed from the 5DX System,
the Inner Barrier’s Air Cylinder will lose pressure and the Inner Barrier will drop
below the bottom of the X-ray Tube. In this position if the XYZ Stage Assembly
is moved when not at the Z-down position, the XYZ Stage Assembly may hit the
Inner Barrier. Do not move the XYZ Stage Assembly unless the Inner Barrier is
in the fully open or fully closed position or when the XYZ Stage Assembly is not
at the Z-down position.
