Agilent 5DX Service Guide 8-15
5DX Series 3 Imaging Subsystem Components
X-ray Confirmation and Adjustment
The X-ray Scan Controller needs to be confirmed and adjusted for each FOV used
in a panel program. The X-ray Scan Controller can be confirmed and adjusted by
running a utility program, called
Major X-ray Scan Adjustment, accessed from
the Confirm and Adjust menu in the User Interface. This utility determines the
optimum X-ray deflection, then interpolates the remaining points to fill the X-ray
Scan Controller’s memory.
WA R N I NG The X-ray Tube Assembly and the X-ray High Voltage Power Supply
contain high voltages capable of causing injury. There are no user
serviceable parts within the X-ray Tube Assembly or the X-ray High
Voltage Power Supply. Any attempt to adjust or tamper with the unit could
result in permanent damage to the X-ray Tube. Contact the Agilent
Response Center regarding ANY changes to the X-ray parameters. The
5DX System is a certified cabinet X-ray system, that has been factory set to
conform with Government Regulations concerning health and safety
127( There are no user serviceable parts contained within the X-ray Tube
Assembly. The following information is provided for an
understanding of the system only.
127( For support purposes, the following components make up the High
Voltage Subsystem: X-ray Tube Assembly, X-ray High Voltage
Power Supply and the High Voltage Power Supply Cable.
