7SENSe Subsystem
179 U2000 Series Programming Guide
Parameters
Example
Reset Condition
On reset, the duty cycle is set to 1% (DEF).
Query
[SENSe[1]]:CORRection:DCYCle|GAIN3[:INPut][:MAGNitude]?
[MIN|MAX]
The query returns the current setting of the duty cycle or the values associated
with MIN and MAX.
Item Description/Default Range of Values
numeric_value A numeric value for the duty cycle.
• DEF: the default value is 1 %
• MIN: 0.001%
• MAX: 99.999%
The units are PCT, and are optional,
0.001 to 99.999 PCT
DEF
MIN
MAX
CORR:DCYC 90PCT
This command sets a duty cycle of
90%.
