Input sensitivity - lineInput sensitivity - line
buildoutbuildout
Drop and insertDrop and insert
Timing sourceTiming source
FollowsFollows
For the switching method between PDH Tx and DSn Tx, refer to Physical Setup
in "E1 Setup and Status". Touching OffOff radio button disables the transmitter.
This screen allows you to make the physical setup of the PDH transmitter in
DS1/J1 mode. It can also be used to inspect the current status of the selected
port.
The configuration options available in the setup area of the screen are
described below. The status information is described in a separate section.
The output signal goes to the corresponding Bantam connector.
Select the line build-out. The available values are:
Rx short haul; Tx 1-133 ftRx short haul; Tx 1-133 ft
Rx short haul; Tx 133-266 ftRx short haul; Tx 133-266 ft
Rx short haul; Tx 266-399 ftRx short haul; Tx 266-399 ft
Rx short haul; Tx 399-533 ftRx short haul; Tx 399-533 ft
Rx short haul; Tx 533-655 ftRx short haul; Tx 533-655 ft
Rx gain mode (Monitor)Rx gain mode (Monitor)
Rx long haul; Tx 0 dbRx long haul; Tx 0 db
Rx long haul; Tx -7.5 dbRx long haul; Tx -7.5 db
Rx long haul; Tx -15 dbRx long haul; Tx -15 db
Rx long haul; Tx -22.5 dbRx long haul; Tx -22.5 db
Select the source for the transmitter.
OnOn: transmits the received data which the data generated in the Network Master
has added.
OffOff: transmits the data generated in the Network Master.
Select the clock source.
InternalInternal: Internal clock of the module
ExternalExternal: The clock provided from the Ext Clock connector
ReceivedReceived: The clock generated from the received signal
When ExternalExternal or ReceivedReceived is set, the right hand lamp indicates whether clock
is detected or not.
55..44..11..22 DS1/J1 Signal SetupDS1/J1 Signal Setup
Touching the navigation area button which represents the transmitter's DS1/J1
layer will display the screen.
To make the Port 2 transmitter follow the Port 1 transmitter (i.e. copy its
settings) when using Port 1 and Port 2, touch the drop-down menu in the
navigation area and select the Tx1Tx1. The Port 2 settings continue to follow the
Port 1 transmitter change. The default setting is NoneNone. Note that the Port 1
transmitter cannot follow the Port 2 transmitter.
Frame tab pageFrame tab page
The FrameFrame tab page contains the following parameters:
SDH/SONET/PDH/DSn ApplicationsSDH/SONET/PDH/DSn Applications
146146
