99..44 ReflectorReflector
In
Fiber Channel Reflector
mode, the Network Master loops incoming traffic on a
port, swapping ID addresses.
99..44..11 Ports Setup and StatusPorts Setup and Status
The first step in running an application is to set up the port interfaces. This is
done on the Ports SetupPorts Setup screen, which also provides port status information.
The setup options and status information related to the Fibre Channel interface
are described in a separate section:
FC Setup and Status
For applications also including an OTN interface, you can find a description of
the setup options and status information for OTN in the following section:
OTN Setup and Status
Please refer to the sections relevant for your current port setup requirements.
99..44..22 Test SetupTest Setup
99..44..22..11 ControlControl
When you go to the test setup of the Fibre Channel Reflector application, the
following screen is displayed.
