1111..44 MU100090A High Performance GPS Disciplined OscillatorMU100090A High Performance GPS Disciplined Oscillator
The following sections describe the specifications for the Network Master Pro
MU100090A module.
1111..44..11 ConfigurationConfiguration
- Module -- Module -
MU100090A High Performance GPS Disciplined Oscillator
- Standard Accessory -- Standard Accessory -
J1702A GPS Antenna 1
J1705A AUX Conversion Adaptor 1
J1710A BNC Cable (20cm) 2
- Options -- Options -
MU100090A-ES210 2 Years Extended Warranty Service
MU100090A-ES310 3 Years Extended Warranty Service
MU100090A-ES510 5 Years Extended Warranty Service
- Optional Accessory -- Optional Accessory -
J1705A AUX Conversion Adaptor
J1706A GPS Antenna
J1710A BNC Cable (20cm)
1111..44..22 Electrical performance and functionElectrical performance and function
Rubidium oscillator
Aging:
2.5×10
-11
(Daily)
1×10
-10
(Monthly)
1×10
-9
(Yearly)
10MHz Clock Output Connector: BNC Jack
Level: TTL, 50 Ω
1PPS Output Connector: BNC Jack
Level: TTL, 50 Ω
Holdover: 300 ns per 10000 s
Holdover should be executed after Rubidium oscillator
is:
turned power on for three hours or more
and
synchronized with GPS or external 1PPS for 30
minutes or more
At constant temperature
1PPS Sync Input Makes built-in Rubidium oscillator synchronize with 1PPS.
Connector: BNC Jack
Level: TTL, 50 Ω
Input Frequency Range: ±10 ppb
