88..33 Pass ThroughPass Through
CPRI/OBSAI Pass Through
enables non-intrusive in-service monitoring. All traffic
received on a port is forwarded on the other port and vice versa. Traffic between the
two network DUT elements is monitored as illustrated below.
88..33..11 Ports Setup and StatusPorts Setup and Status
The first step in running an application is to set up the port interfaces. This is
done on the Ports SetupPorts Setup screen, which also provides port status information.
The setup options and status information related to the CPRI/OBSAI interface
are described in a separate section:
CPRI/OBSAI Setup and Status
88..33..22 Test SetupTest Setup
88..33..22..11 ControlControl
Refer to "Control" in the BERT section.
88..33..22..22 ThresholdsThresholds
Refer to Thresholds of BERT section in "CPRI/OBSAI Applications".
88..33..33 Test ResultsTest Results
88..33..33..11 SummarySummary
When you go to the test results of the CPRI Through application, the following
screen is displayed.
