In this instrument, cooling air is taken in through the side panel, and hot air is
exhausted through the bottom panel. When using MT1000A on a desk, open
the support stand on the rear panel
11..77..33 ESD (Electrostatic Discharge)ESD (Electrostatic Discharge)
Modules and options for the Network Master contain electronic devices that are
sensitive to ESD (Electro Static Discharge). Therefore, all ESD sensitive items are
delivered from Anritsu in antistatic shielding packages.
Electrostatic discharge during installation can result in destruction or
degradation of these devices. The damage may lead to equipment failure later.
When you install or remove modules, it is your responsibility to control ESD.
To control ESD, take the issues described below into consideration.
CAUTIONCAUTION
Avoid build-up of electrostatic chargeAvoid build-up of electrostatic charge
Keep your workplace clear of any item that can generate electrostatic charges,
e.g. all items that are not made of antistatic materials.
Minimize the exposure to ESDMinimize the exposure to ESD
Keep ESD sensitive items in antistatic shielding packaging as long as
possible.
Do not remove ESD sensitive items from equipment or the antistatic shielding
packaging unless you are connected to the equipment with a grounding wrist
strap (as described later).
Return ESD sensitive items to antistatic shielding packaging.
Keep equipment, the ESD sensitive items and yourself at the same staticKeep equipment, the ESD sensitive items and yourself at the same static
potentialpotential
If your workplace is already prepared for handling ESD sensitive items, then
follow your usual procedure. If not, you should follow the procedure below
using a ground wrist strap.
1. Attach the wrist end of the wrist strap firmly around your wrist and the other
end to the equipment chassis or ground plug.
2. Keep the wrist strap on while you install or remove ESD sensitive items. Do
not remove the wrist strap until the ESD sensitive parts are either installed or
returned to the antistatic shielding package.
11..77..44 Optical SurfacesOptical Surfaces
The optical interfaces - transmitter as well as receiver - are very sensitive to
contamination. Be aware that contamination of the optical surfaces may result
in severe loss of signal.
CAUTIONCAUTION
