MT1000A_Software with MU100011A
MT1000A_Software
"MT1000A_Software with MU100011A" is consisted from two files. Select both files
when upgrading the software.
Note that installing "MT1000A_Software" is not able to work the MU100011A.
1. Click Select FileSelect File to launch the dialog box.
2. Select the software file.When you select the folder where you unpacked the
installer, the installer file will be selected automatically. Multiple files can be
selected by selecting a file while holding down the CtrlCtrl key.
3. Progress bar shows Upload Progress. Clicking CancelCancel aborts the file
uploading.
4. After file uploading finishes, click Start InstallationStart Installation.
Clicking Start InstallationStart Installation will reboot the Network Master. Installation process cannot be
remotely monitored. Please reconnect after a few minutes.
33..55..66 Remote Wake UpRemote Wake Up
If Network Master is in Stand-by mode, it is possible to remotely get the unit
into the Operation state.
1. Click StartStart > All Programs > Anritsu > MX100001A folder.
2. Click MX100001A-V*.**-RemoteMX100001A-V*.**-Remote.
3. On the Control Software startup screen, enter the IP address of the Network
Master in the Remote Unit IP AddressRemote Unit IP Address field.
4. Click StartStart in Wake UpWake Up tab.
5. After the progress bar reaches 100%, click OKOK in the dialog box.
33..55..77 Remote ResetRemote Reset
The Remote Reset function can be helpful if the unit is on a remote site and
unexpectedly freezes or becomes unresponsive. The possibility to remotely
reset an instrument can be disabled by unchecking the Enable Remote ResetEnable Remote Reset
check box in the Remote Control options.
To remotely force a reboot the Network Master, specify the Network Master
using its serial number.
1. On the Control Software startup screen, enter the IP address of the Network
Master in the Remote Unit IP AddressRemote Unit IP Address field.
2. Enter the serial number in the Controller SNController SN field on the ResetReset tab.
3. Click StartStart on the ResetReset tab.
4. After the progress bar reaches 100%, click OK in the dialog box.
Make sure to save measurements and settings before initiating Remote Reset function.
The Reset will force the Network Master to reboot. All unsaved or ongoing
measurements will be lost.
33..55..88 Stand-alone EditorStand-alone Editor
