Physical StatusPhysical Status
Alarm/Error StatusAlarm/Error Status
Monitor ButtonMonitor Button
Touch 'Normal' or 'Inverse' pattern type.
Touching the 'ANSI standard' button will apply ANSI/IEEE 1007
recommended Pattern typePattern type for 45 Mbit data rates (PRBS 23 Inverse).
User patternUser pattern
User pattern field is enabled if Pattern type is set to User [32] bitUser [32] bit or User [2084]User [2084]
bitbit. Touch the User patternUser pattern field and use the launched Pattern EditorPattern Editor dialog box
to define the user pattern. Depending on the selected pattern type, different
user pattern setup options will be available.
The length can be any length from 1 bit to 32 bits or from 1 bit to 2048 bits.
55..66..33 Status InformationStatus Information
This section describes the status information available for the DS3 layer in the
status area of the Ports SetupPorts Setup screen.
55..66..33..11 Status SummaryStatus Summary
The status summary displayed for the DS3 layer consists of the following
information:
The topmost part of the status area gives you access to information about the
current physical status of the selected interface. A summary consisting of the
most relevant status indicators is displayed constantly. By touching the
summary, you can launch a display that contains the detailed status
information.
The middle part of the status area gives you access to alarm and error
information for the selected interface. The current status is indicated by the
lamp color.
A summary consisting of the most relevant alarm/error indications is displayed
constantly. By touching the summary, you can launch a display that contains
all alarms/errors.
At the bottom of the status area are a number of buttons that give you access to
various capture/monitor information. By touching a button, you can launch the
corresponding information dialog.
AlignmentAlignment
55..66..33..22 Physical DetailsPhysical Details
Refer to Physical Details in "E1 Setup and Status". The nominal bit rate of DS3
is 44 736 000 bps.
55..66..33..33 Alarms and ErrorsAlarms and Errors
Touching the middle summary box in the status area of the Ports SetupPorts Setup screen
allows you to launch the screen shown below.
