66..55 Mon/GenMon/Gen
Ethernet Monitor/Generate
is typically used for out-of-service and performance
testing. It is possible to perform a passive, non-intrusive monitoring or at the same
time transmit test data, which can be reflected for further evaluation and testing of
the network.
66..55..11 Ports Setup and StatusPorts Setup and Status
The first step in running an application is to set up the port interfaces. This is
done on the Ports SetupPorts Setup screen, which also provides port status information.
The setup options and status information related to the Ethernet interface are
described in a separate section:
Ethernet Setup and Status
For applications also including an OTN interface, you can find a description of
the setup options and status information for OTN in the following section:
OTN Setup and Status
Please refer to the sections relevant for your current port setup requirements.
66..55..22 Test SetupTest Setup
Copy frame content to other stream(s)Copy frame content to other stream(s)
This feature allows you to copy the frame content of the stream that you are
currently configuring to all streams in another port or to a single stream.
Touching the Copy ToCopy To button opens a drop-down menu from which you can select the
relevant port and AllAll or a specific stream.
66..55..22..11 ControlControl
Refer to "Control in BERT Test Setup subsection for the operation.
66..55..22..22 GeneratorGenerator
Refer to "Generator in BERT Test Setup subsection for the operation.
66..55..22..33 Streams - ProfileStreams - Profile
Touching the Streams - ProfileStreams - Profile button in the navigation area displays the
following screen.
The FollowFollow button appears when the Port 2 settings can follow Port 1.
