Module PresentModule Present
TransceiverTransceiver
InformationInformation
Power monitorPower monitor
When the optical transceiver is QSFP+ or QSFP28, I2C analysisI2C analysis and SettingsSettings
appear.
When the optical transceiver is CFP4, MDIO analysisMDIO analysis and SettingsSettings appear.
Green indicates that an optical transceiver is currently mounted.
Select the information from pull down menu.
Wavelength and bit rateWavelength and bit rate shows the nominal wavelength and bit rate.
ComplianceCompliance shows the available standards.
Vendor informationVendor information shows the data stored in the optical transceiver.
Tune wavelengthTune wavelength
When the optical transceiver is a tunable SFP, following items are displayed for
Wavelength and bit rateWavelength and bit rate.
Bit rate, Channel, Wavelength, Frequency, First frequency, Last frequency,
Grid spacing
Touching ChannelChannel or WavelengthWavelength value opens
the dialog box to set the wavelength.
The optical power read out from the transceiver is displayed.
The transmitting optical power is displayed in left column. The received optical
power is displayed in right column.
77..11..44 Error/Alarm InsertionError/Alarm Insertion
This section describes the errors or alarms insertion for the OTN layer on the
Application toolbar.
