66..66 Pass ThroughPass Through
Ethernet Pass Through
enables non-intrusive in-service monitoring for both fast
troubleshooting and detailed analysis of the live traffic on a network. All traffic
received on a port is forwarded on the other port and vice versa. Traffic between the
two network DUT elements is monitored as illustrated below.
66..66..11 Ports Setup and StatusPorts Setup and Status
The first step in running an application is to set up the port interfaces. This is
done on the Ports SetupPorts Setup screen, which also provides port status information.
The setup options and status information related to the Ethernet interface are
described in a separate section:
Ethernet Setup and Status
