Physical StatusPhysical Status
Alarm/Error StatusAlarm/Error Status
Capture/MonitorCapture/Monitor
StatusStatus
Tx DataTx Data : Expected MSI are copied from OH Preset data.
Received DataReceived Data: Expected MSI are set from received MSI data.
77..11..33 Status InformationStatus Information
This section describes the status information available for the OTN layer in the
status area of the Ports SetupPorts Setup screen.
77..11..33..11 Status SummaryStatus Summary
The status summary displayed for the OTN layer consists of the following
information:
The topmost part of the status area gives you access to information about the
current physical status of the selected interface. A summary consisting of the
most relevant status indicators is displayed constantly. By touching the
summary, you can launch a display that contains the detailed status
information.
The middle part of the status area gives you access to alarm and error
information for the selected interface. The status is indicated by the lamp color.
You can choose whether to view only the current alarm and error status, or to
view all alarms and errors in the alarm trap since it was last reset.
A summary consisting of the most relevant alarm/error indications is displayed
constantly. By touching the summary, you can launch a display that contains
all alarms/errors.
At the bottom of the status area are below buttons that give you access to
various capture/monitor information. By touching a button, you can launch the
corresponding information display.
OH captureOH capture
Tributary scanTributary scan
TransceiverTransceiver
77..11..33..22 Physical DetailsPhysical Details
Touching the topmost summary box in the status area of the Ports SetupPorts Setup screen
displays the status shown below.
