Alarms/Errors/Alarms/Errors/
OthersOthers
99..11..44 Errors/Alarms InsertionErrors/Alarms Insertion
This section describes the errors and alarms insertion for the Fiber Channel
interface on the Application toolbar.
Select the port to insert errors, and the stimuli type. The settings items vary
depending on the selected stimulus type.
99..11..44..11 Fibre Channel alarmsFibre Channel alarms
Select an alarm option in the drop-down menu.
Alarms will be inserted continuously.
NoneNone: Does not insert alarms.
Link resetLink reset: Inserts Link_Reset primitive sequences.
Ordered Set: K28.5 - D9.2 - D31.5 - D9.2
Link reset responseLink reset response: Inserts Link_Reset_Response primitive sequences.
Ordered Set: K28.5 - D21.1 - D31.5 - D9.2
Not optionalNot optional: Inserts Not_Operational primitive sequences.
Ordered Set: K28.5 - D21.2 - D31.5 - D5.2
OfflineOffline: Inserts Offline primitive sequences.
Ordered Set: K28.5 - D21.1 - D10.4 - D21.2
99..11..44..22 Fibre Channel errorsFibre Channel errors
1. Select an error option in the ErrorError drop-down menu.
NoneNone: Does not insert errors.
BitBit: Inserts a bit error into the content part of FC frames.
SymbolSymbol: Inserts a symbol of 10 bit pattern which makes a 10b/8b
conversion error.
R_RDYR_RDY:Inserts a symbol of 10 bit pattern which makes a 10b/8b
conversion error.
When Port mode is set to FC1000FC1000, this option does not appear.
CRCCRC: Inserts a bit error into CRC part of FC frames.
When Framing is set to SOF:Header:EOFSOF:Header:EOF, this option does not appear.
2. In the InsertionInsertion drop-down list, select an insertion mode.
OffOff: Turns off inserting errors.
