ManualManual: Inserts the specified number of errors if you touch the Error
Insert icon.
Burst / secBurst / sec: Inserts the specified number of errors in one second
periodic.
Burst / 10 secBurst / 10 sec: Inserts the specified number of errors in ten second
periodic.
Burst*1E-02Burst*1E-02 to Burst*1E-07Burst*1E-07: Inserts errors of burst length at the
specified rate continuously.
For example, Error burst lengthError burst length is set to 3 and Burst*1E-06Burst*1E-06 is selected,
the three errors will be inserted per one million blocks. The Error
Insert icon shows only status.
3. Touch the Burst lengthBurst length field to set the number of errors to insert.
4. When Insertion is set to ManualManual, touch the Error Insert icon.
99..11..44..33 Fibre Channel frequencyFibre Channel frequency
Touch the field to set Fibre Channel frequencyFibre Channel frequency. Enter the desired deviation in
the Tx Deviation field. A positive value increases the frequency.
