33..55 Remote OperationRemote Operation
With the MX100001A MT1000A/MT1100A Control Software (hereafter,
"Control Software") application installed, your PC is capable of supporting
remote access to the Network Master. Control Software simulates the panel
operation of the Network Master, allowing you to operate and view results on a
PC through a LAN or Internet connection. If more Network Masters are linked
to a network, they can be remotely controlled by the same PC, one at a time.
33..55..11 Installation of Control SoftwareInstallation of Control Software
Operation EnvironmentOperation Environment
OS Windows 7/8.1 English/Japanese
Interface Ethernet 100BASE-TX/1000BASE-T
Display 800 × 600 dots or more
1. Copy the installer stored in the Network Master to your PC, by USB memory
stick or the file sharing function.
File Name: MX100001A-Setup-x.xx-xxxxx.exe
"x"s in the file name mean numerics showing the version.
2. Double click the installer file.
3. If User Account Control dialog box appears, click YesYes.
4. After the installation finishes, click CloseClose.
Click StartStart > All Programs > Anritsu > MX100001A folder. Confirm that
following programs appear. "V*.**" is replaced to the version name.
MX100001A-V*.**-Editor
MX100001A-V*.**-Remote
MX100001A-V*.**-Viewer
V*.**-Uninstall
When installing a new version of the Control Software, previous versions are not
automatically uninstalled. To manually uninstall a Control Software version, execute
"Uninstall" from the Control Software folder from the Start menu of Windows.
33..55..22 Connection and SetupConnection and Setup
To make Remote Operation application communicate with Network Master:
1. Connect an Ethernet network cable to the LAN connector on your Network
Master and link this to a Local Area Network.
2. Assign an IP address to the Network Master. This is done in the
Ethernet
setting available from the Network screen as described in the
Graphical User
Interface
chapter.
3. Enable Allow remote PCAllow remote PC in the Remote Control.
4. Display the Resource Monitor. Confirm that the IP address and "running Tests
and Views" appear.
