To register string, touch a blank button. Touching labeled button adds the
string to file name.
Import/ExportImport/Export: Saves string on buttons to a file or loads string from a file.
ResetReset: Erases string on all buttons.
CancelCancel: Discards edited string and closes dialog box.
OKOK: Applies edited string and closes dialog box.
Start NumberStart Number
Touch the field and set the start number of value used in the file name.
Include DateInclude Date
If selecting the check box, date will be appended in the file name.
Include NumberInclude Number
If selecting the check box, a file number will be appended in the file name.
The file name to be generated first is displayed under this item.
1010..44..44 Test ResultsTest Results
When you go to the test results of the VIP application, the following screen is
displayed.
This screen displays the image captured by the Video Inspection Probe.
Analyzing an image of the fiber edge surface is also available.
