Test ConditionTest Condition
ThresholdThreshold
Allows you to define the test duration in one of two ways:
ModeMode
SingleSingle - Used to perform RTD test once.
RepeatRepeat - Used when a
persistent RTD test
is needed.
Measurement periodMeasurement period
Select the measurement period from 0.5 seconds0.5 seconds to 10 seconds10 seconds.
55..1010..55..22 ThresholdThreshold
Touching the ThresholdThreshold button in the navigation area displays the following
items.
Maximum limitMaximum limit
Allows you to specify a threshold value of RTD in micro seconds (μs).
55..1010..66 Test ResultsTest Results
55..1010..66..11 SummarySummary
Touching the SummarySummary button in the navigation area will display the screen
shown below.
This screen presents a summary of the RTD test results, for all of the ports
included in the test. For each port, the information consists of:
Measurement count
Minimum, average, and maximum round-trip delay times in micro seconds
Threshold value
55..1010..66..22 DetailedDetailed
Touching the DetailedDetailed button in the navigation area will display the screen
shown below.
