56001
(default)
SCPI server port, user configurable. Used by remote SCPI
clients. Refer to Remote Control section for details how to setup.
5900
(default)
VNC (TCP), user configurable. Used by remote VNC clients.
5800
(default)
VNC over HTTP, user configurable. Used by remote VNC over
HTTP tunnel clients.
Refer to VNC section for details how to setup VNC
communication ports.
135, 137,
138, 139,
445
File Sharing, fixed ports.
33..55..44 Starting Control SoftwareStarting Control Software
1. Open Anritsu-MX100001A folder from Start menu.
2. Click MX100001A-V*.**-RemoteMX100001A-V*.**-Remote.
If Windows Security Alert appeared, click Allow accessAllow access.
Before connecting to the Network Master, confirm that the response from the Network
Master is quick enough. If the response from Network Master via the Ethernet network is
too late, a connection fails and the message "Network connection is too slow!" appears.
Executing Remote Operation on control PC:
1. If Control Software launched, the initial screen for remote operation appears
as below.
When two or more network interface cards are available, Use NetworkUse Network
InterfaceInterface selection appear. Touch the field to select a interface.
2. Enter the IP address of the Network Master to Remote Unit IP AddressRemote Unit IP Address.
