66..44 Channel StatisticsChannel Statistics
The Channel Statistics test separates incoming frames into channels based on a
number of defining characteristics (
Definitions
) and shows information about each
channel (
Statistics
). The test is mostly used for in-service monitoring, where it
provides data for detailed analysis of the traffic types present in the network.
66..44..11 Ports Setup and StatusPorts Setup and Status
The first step in running an application is to set up the port interfaces. This is
done on the Ports SetupPorts Setup screen, which also provides port status information.
The setup options and status information related to the Ethernet interface are
described in a separate section:
Ethernet Setup and Status
66..44..22 Test SetupTest Setup
66..44..22..11 ControlControl
Refer to "Control in "BERT" section for the operation.
66..44..22..22 GeneratorGenerator
Refer to "Generator in "BERT" section for the operation.
66..44..22..33 Stream - profileStream - profile
Refer to "Streams - profile in "Mon/Gen" section for the operation.
66..44..22..44 Stream - Meas.Stream - Meas.
Refer to "Streams - Meas. in "Mon/Gen" section for the operation.
66..44..22..55 DefinitionsDefinitions
Touching the DefinitionsDefinitions button in the navigation area displays the following
screen.
