88..11..44 Error/Alarm InsertionError/Alarm Insertion
This section describes how to configure settings for inserting errors or alarms
by using the Application toolbar of CPRI/OBSAI.
Select the port to insert errors, and the stimuli type. The settings items vary
depending on the selected stimulus type.
88..11..44..11 CPRI/OBSAI AlarmsCPRI/OBSAI Alarms
1. Select the CPRI/OBSAI AlarmsCPRI/OBSAI Alarms.
2. Select the AlarmAlarm item.
3. Select the InsertionInsertion.
OffOff: Does not insert alarms.
PermanentlyPermanently: Inserts alarms permanently.
88..11..44..22 CPRI/OBSAI ErrorsCPRI/OBSAI Errors
1. Select the CPRI/OBSAI ErrorsCPRI/OBSAI Errors.
2. Select the ErrorError item.
3. Select the InsertionInsertion.
OffOff: Turns off inserting errors.
ManualManual: Inserts the specified number of errors if you touch the Error
Insert icon.
Touch the Burst lengthBurst length field to set the number of errors to insert.
1E-041E-04 to 1E-101E-10: Inserts errors at the specified rate continuously.
4. When selecting ManualManual, touch the Error Insert icon ( ) to insert an error.
88..11..44..33 CPRI/OBSAI FrequencyCPRI/OBSAI Frequency
1. Select the CPRI/OBSAI FrequenciesCPRI/OBSAI Frequencies.
2. Touch the Frequency OffsetFrequency Offset field to set an offset in ppm. If setting a positive
value, the frequency will shift higher side.
