Received 10 bit sequence is defined as '10B error code' in 8B/10B conversion
table.
Pattern errorPattern error : Bit error of the pattern
Remote
Lights in red when the receiving bit in L1 Inband Protocol is "1". These bits are
located in Z.130.0 in the hyperframe.
Remote LOSRemote LOS: Loss of Signal detection
Remote LOFRemote LOF: Loss of Frame detection
RAIRAI: Remote Alarm Indication
SDISDI: SAP (Service access point) Defect Indication
ResetReset: Master - Reset acknowledge, Slave - Reset request
Link
Shows the CPRI Link status.
Link State and Port Role appear when Start up is set to EnabledEnabled.
Rx
Protocol version
HDLC rate
Pointer
Tx
Protocol version
HDLC rate
Pointer
88..11..33..44 TransceiverTransceiver
Refer to Transceiver in "Ethernet Setup and Status".
