LinkLink
LoginLogin
Accumulated Accumulated differencedifference
The accumulated difference between the received signal's bit rate and the
nominal bit rate is shown. The information is presented as the number of bits
of difference detected over the accumulation period.
This is important information for identifying small frequency differences, which may not
be visible by showing the current bit rate difference.
The accumulated difference information is accumulated continuously. The
accumulation is reset when measurement is started or restarted.
The link status information consists of the following parameters:
Signal PresentSignal Present
Indicates the detection/loss of a valid signal (bit synchronization).
Sync AcquiredSync Acquired
Indicates word synchronization acquired/lost.
Link StatusLink Status
Indicates the current link status.
Fabric LoginFabric Login
Lamp icon lit in green when login to an F-port.
ELPELP
Lamp icon lit in green when Exchange Link Parameters have been exchanged
with an E-port.
Port LoginPort Login
Lamp icon lit in green when login to an N-port.
99..11..33..33 Alarms and ErrorsAlarms and Errors
The middle summary box in the status area of the Ports SetupPorts Setup screen indicates
alarms and errors. Status is indicated by the use of colored Lamp icons.
TrafficTraffic: Traffic is detected.
Pattern SyncPattern Sync: Pattern Sync is detected.
Pattern ErrorPattern Error: Pattern Error is detected.
99..11..33..44 TransceiverTransceiver
Refer to Transceiver in "Ethernet Setup and Status" section.
