TTI detectionTTI detection
TTI detection allows you to select the detection method for SM, PM, and TCM1-
6.
OffOff Disables the TTI (Trail Trace Identifier) detection.
SAPISAPI (Source Access Point Identifier)
DAPIDAPI (Destination Access Point Identifier)
SAPI and DAPISAPI and DAPI
SAPI, DAPI and OperatorSAPI, DAPI and Operator (32-Byte Operator specific)
PLM detectionPLM detection
Selecting OnOn enables the PLM (Payload Label Mismatch) detection.
77..11..22..55 MSIM detectionMSIM detection
Touching an MSIM detectionMSIM detection button on the Ports SetupPorts Setup screen launches the
MSIM DetectionMSIM Detection dialog box.
The dialog box is used to set the detection method of MSIM (Multiplex
Structure Identifier Mismatch).
Setup FollowSetup Follow
Select the source of the Expected MSI in the drop-down menu. The expected
MSI is displayed in the dialog box.
(None)(None) : MSIM is not detected.
