Path to the selected form (for example, "ODU2-ODTU12(PT=21)-ODU1 #2")
Errors and alarms detected at the selected channel.
Touching the button in green does not launch the dialog box.
To change TP to scan, touch the ScanScan button.
Tributary Scan Results are cleared, when close the dialog box, move other status area or
move other screens.
Stop scanningStop scanning
Touching the Scan StopScan Stop button stops the scanning session.
77..11..33..66 TransceiverTransceiver
Touching the TransceiverTransceiver button in the status area of the Ports SetupPorts Setup screen
displays the status shown below.
This screen presents status information about the optical transceiver.
When the optical transceiver is SFP or SFP+, I2C analysisI2C analysis appears. Refer to
description of Transceiver in Ethernet Applications.
