Selecting notationSelecting notation
Open the left drop-down menu in the top row of buttons to select which results
you want to display on the screen.
OTN - Alarms/ErrorsOTN - Alarms/Errors
OTN - PerformanceOTN - Performance
CPRI/OBSAI - Alarms/ErrorsCPRI/OBSAI - Alarms/Errors
CPRI/OBSAI - FrameCPRI/OBSAI - Frame
Delay - Round Trip TimeDelay - Round Trip Time
OTN options appear if the CPRI signal is carried by OTN.
Round Trip Time appears if DelayDelay check box is selected on Delay screen in
Test Setup of BERT application.
Touch a specific cell in a result table to zoom in on the corresponding result
item. The CountCount and RatioRatio fields are displayed on a ZoomZoom tab page. A Time vs.Time vs.
StatisticsStatistics tab page is also available. Use the BackBack button or touch the zoom
filed to return to the statistics screen.
Select the required notation for the results from the notation drop-down menu.
UnformattedUnformatted - e.g. 71892
SI prefixSI prefix - e.g. 71.891 k (k means "kilo")
EngineeringEngineering - e.g. 71.892E3
ScientificScientific - e.g. 7.1892E4
ResultsResults
Results are displayed according to your choice.
OTN Alarms/Errors Refer to Results in "OTN Application"
OTN Performance Refer to Results in "OTN Application"
CPRI/OBSAI - Alarms/Errors Results Alarms
Errors
CPRI/OBSAI - Frame Results Frame count
CPRI/OBSAI - Round Trip Delay Results Delay
Measurement count
