This screen provides information on the frame alignment when available.
F-Bit and M-bit are displayed when the frame type is J1J1 or ESFESF.
F-Bit and S-bit are displayed when the frame type is SF/D4SF/D4.
In-band FDLIn-band FDL
Displays the In-band FDL (Facility Data Link) data.
TriggerTrigger
Set OnOn to hold displaying FDL if In-band FDL matches. If set OffOff, the latest In-
band FDL is displayed.
User DefinedUser Defined
Select the check box to edit the user defined inband code. Touching the field
launches the pattern editor.
You can set the user defined inband code for the transmitter by the stimuli setup in
Application Toolbar.
55..44..33..55 CASCAS
Touching the CASCAS button in the status area of the Ports SetupPorts Setup screen launches
the status shown below.
