The event log listThe event log list
The test start event (Started) and stop event (Stopped) are always shown in the event
log.
The ViewView setting applies a port filter. A single port or all ports can be selected.
Events with no port association will always pass.
The CSV exportCSV export button is for writing all events (un-filtered) to a file in a CSV
format (Comma Separated Values). The separator used can be configured in
the Instrument ToolbarInstrument Toolbar > Configuration > General> Configuration > General menu screen, under
MiscellaneousMiscellaneous. It is not possible to export the file during a test.
The events are displayed in a scrollable table. The content of the seven
columns are:
No.No.
The index in the log.
TimeTime
The time when the event was detected.
PortPort
Port number for events related to a port. Otherwise this field is blank.
TypeType
Event type icon.
Alarm events are indicated by a red icon.
Error events are indicated by a yellow icon.
Threshold events are indicated by either a red or yellow icon with a T in
the middle.
Src.Src.
The source of the event. This row denotes the originating interface/technology
or application.
DescriptionDescription
The event description. For alarms and errors there are a one-to-one relation
to the items found in the StatisticsStatistics screen.
Dur./CountDur./Count
For alarms, this is the alarm duration measured in seconds. An alarm event
where the duration is not know yet, will show the text OnOn.
For errors, this is the number of errors in the errored second.
Event log and statistics can show different alarm duration and error count
when values are summed up an compared. This is because statistics discards
the last interval if it is not complete when the test is stopped. There will be no
differences if the test duration is set to a multiple of the interval length or if
intervals are disabled.
55..99..33..44 StatisticsStatistics
Touching the StatisticsStatistics button in the navigation area displays the screen shown
below.
