This screen presents an OAM Log of the test results. Note that the layout of the
dialog box depends on the currently selected OAM protocol.
66..22..33..44 Event LogEvent Log
Touching the Event LogEvent Log button in the navigation area displays the screen
providing the event log data. Refer to Event Log of SDH/SONET/PDH/DSn
BERT application.
66..22..33..55 StatisticsStatistics
Touching the StatisticsStatistics button in the navigation area displays the screen shown
below.
This screen presents a detailed analysis of the test results. You can choose to
view either the total results from measurement start or the results of a specific
interval during the test. You can also zoom in on a specific result item. The
results can be displayed either in table (list) form or as a graph.
Selecting which results to viewSelecting which results to view
