PSI valuePSI value Payload typePayload type
0x0A0x0A STM-1 mapping into OPU0
0x0B0x0B STM-4 mapping into OPU0
0x0C0x0C FC-100 mapping into OPU0
0x0D0x0D FC-200 mapping into OPU1
0x0E0x0E FC-400 mapping into OPUflex
0x0F0x0F FC-800 mapping into OPUflex
0x100x10 Bit stream with octet timing mapping
0x110x11 Bit stream without octet timing mapping
0x120x12 IB SDR mapping into OPUflex
0x130x13 IB DDR mapping into OPUflex
0x140x14 IB QDR mapping into OPUflex
0x150x15 SDI mapping into OPU0
0x160x16 (1.485/1.001) Gbit/s SDI mapping into OPU1
0x170x17 1.485 Gbit/s SDI mapping into OPU1
0x180x18 (2.970/1.001) Gbit/s SDI mapping into OPUflex
0x190x19 2.970 Gbit/s SDI mapping into OPUflex
0x1A0x1A ESCON mapping into OPU0
0x1B0x1B DVB_ASI mapping into OPU0
0x1C0x1C FC-1600 mapping into OPUflex
0x200x20 ODU multiplex structure supporting ODTUjk only (AMP only)
0x210x21
ODU multiplex structure supporting ODTUk.ts or ODTUk.ts and
ODTUjk (GMP capable)
0x550x55 Not available
0x660x66 Not available
0x800x80
Reserved code for proprietary use (non-standard payload
mappings)
0xFD0xFD NULL test signal mapping
0xFE0xFE PRBS test signal mapping
0xFF0xFF Not available
