Anritsu MT1000A - Page 426

GMPGMP
1. Select the LevelLevel to insert errors.
2. Select the Error ItemError Item.
3. Touch the Error BitsError Bits field to edit bits.
4. Touch the Error InsertError Insert icon. The error is inserted once by touching the icon.
GFPGFP
1. Select the Error ItemError Item.
The available option depends on the Client Signal of Mapping.
2. Select the Insertion ModeInsertion Mode.
3. Touch the Error BitsError Bits field to edit bits.
4. If Insertion Mode is set to "Single", touch the Error InsertError Insert icon. The error is
inserted once by touching the Error InsertError Insert icon.
FEC TestFEC Test
1. Select the Error ItemError Item.
O.182 Poisson (appears only if Client Signal is PRBS.)
Uncorrectable Error
Correctable Error
2. When selecting O.182 Poisson:
a. Insertion ModeInsertion Mode is fixed to "Rate".
Touch the RateRate field to set the error insertion rate.
b. Select the Exclude FASExclude FAS.
Selecting OnOn inserts errors at any position excluding FAS when the
rate is 2.0E-3 or larger. This settings avoids the occurrence of LOF by
inserting errors into FAS.
3. When selecting Uncorrectable Error or Correctable Error:
OTN ApplicationsOTN Applications
426426
