Error InsertionError Insertion
Error/Alarm detectionError/Alarm detection
Error PerformanceError Performance
ResultResult
DS1
LOS, AIS, RAI, OOF, LLS
DS3
LOS, AIS, RAI, LOF, Idle, LSS
Item
E1
FAS, FAS and NFAS, FAS word, CRC4, CRC4 MFAS, Code, Pattern error, CAS
MFAS, E-Bit, Pattern slip, Frame slip, Transparent
E3/E4
Frame, Code, Pattern error, Pattern slip (Code is only available for E3.)
DS1
Pattern error, Pattern slip, CRC-6, F-Bit, S-Bit, BPV, EXZ
DS3
Pattern error, Pattern slip, FEBE, C-Bit, F-Bit, P-Bit, BPV
Timing : Manual, Burst
Alarm detection
E1
LOS, AIS, No Frame, No CRC4 MF, Distant, No sync, No CAS MF, Distant MF
E3/E4
LOS, AIS, No Frame, Distant, No Sync
DS1
LOS, AIS, OOF, RAI, LLS
DS3
LOS, AIS, LOF, RAI, IDLE, LSS
Display : Second
Error Detection
E1
FAS, Pattern error, CRC4, CRC4 MFAS, E-bit, Code, Pattern slip, Frame slip,
Pattern block error for G.826
E3/E4
FAS, Code, Pattern error, Pattern slip, Pattern block error for G.826 (Code is
only available for E3.)
DS1
F-Bit, Pattern, CRC-6, S-Bit, BPV, Pattern slip, EXZ, Pattern block error for
G.826
DS3
BPV, Pattern error, Pattern slips, Parity, C-bit, F-bit, FEBE, Pattern block error
for G.826
Display : Count, Ration
G.821/G.826/M.2100 analysis of the received signal
Status
Current information on:
Alarms and errors
SpecificationsSpecifications
