Port modePort mode
Line rateLine rate
Clock ConfigurationClock Configuration
ContentContent
PatternPattern
CPRI LinkCPRI Link
Alarm InsertionAlarm Insertion
Error InsertionError Insertion
Frequency OffsetFrequency Offset
Alarm DetectionAlarm Detection
Error DetectionError Detection
Remote statusRemote status
LinkLink
TransceiverTransceiver
Off, Normal, Through
CPRI: 614.4 Mbps, 1228.8 Mbps, 2457.6 Mbps, 3072.0 Mbps, 4915.2 Mbps,
6144.0 Mbps, 9830.4 Mbps, 10137.6 Mbps
OBSAI: 768 Mbps, 1536 Mbps, 3072.0 Mbps, 6144.0 Mbps
Timing Source
Internal clock
External clock
GPS
Received clock
Unframed, CPRI Link
PRBS 15, PRBS 20, PRBS 23, PRBS 29, PRBS 31, User 32 bit, OFF
Start up
Enabled, Disabled
Role
Master, Slave
Protocol version
1, 2
HDLC rate
no HDLC, 240 kbit/s, 480 kbit/s, 960 kbit/s, 1920 kbit/s, 2400 kbit/s, Highest
possible
Ethernet
On, Off
Pointer: 20 to 63
Item
Signal Loss, LOS, LOF, LSS, Remote-LOS, Remote-LOF, RAI, SDI, Reset
Item
LCV, SHV, K30.7, Pattern error
Insertion timing
Manual, Rate
±100 ppm 1 ppm step
Signal loss, LOS, LOF, LSS
LCV, SHV, K30.7, Pattern error
Remote LOS, Remote LOF, RAI, SDI, Reset
Rx
Protocol version, HDLC rate, Pointer P
Tx
Protocol version, HDLC rate, Pointer P
Module Present
Transceiver Information
Alarm, Wavelength and bit rate, Compliance, Vendor Information, Output
Control
Power monitor
