Order No./ NameOrder No./ Name
Description Description
(Approx. Distance)(Approx. Distance)
Min. InputMin. Input
SensitivitySensitivity
InputInput
WavelengthWavelength
OutputOutput
PowerPower
OutputOutput
WavelengthWavelength
G0356A
8G FC/10G SR 850 nm SFP+
8G FC/10G SR 850 nm SFP+ -11.1 dBm
840 to 860
nm
-8.2 to -1
dBm
840 to 860
nm
*: For MU100010A only
Specification of optical modules purchased from Anritsu for the MU100011A
with LC connectors (subject to change without further notice):
Order No./ NameOrder No./ Name
Description Description
(Approx. Distance)(Approx. Distance)
Min. InputMin. Input
SensitivitySensitivity
Input WavelengthInput Wavelength Output PowerOutput Power Output WavelengthOutput Wavelength
G0296A
QSFP+
40GBASE-SR4
40GBASE-SR4
Multi mode
850 nm (0.1 km)
-9.9 dBm 840 to 860 nm -8 to 2.4 dBm 840 to 860 nm
G0334A
40G LR4
1310 nm QSFP+
40G Ethernet/OTN
Single mode
1310 nm (10 km)
-11.5 dBm
per Lane
1264.5 to 1277.5
nm
1284.5 to 1297.5
nm
1304.5 to 1317.5
nm
1324.5 to 1337.5
nm
Total: 8.3 dBm
max.
-2 to 2.3 dBm
per Lane
1264.5 to 1277.5
nm
1284.5 to 1297.5
nm
1304.5 to 1317.5
nm
1324.5 to 1337.5
nm
G0364A
100G LR4
1310 nm QSFP28
100G
Ethernet/OTN
Single mode
1310 nm (10 km)
-8.6 dBm
per Lane
1294.53 to 1296.59
nm
1299.02 to 1301.09
nm
1303.54 to 1305.63
nm
1308.09 to 1310.19
nm
Total: 10.5 dBm
max.
-4.3 to 4.5 dBm
per Lane
1294.53 to 1296.59
nm
1299.02 to 1301.09
nm
1303.54 to 1305.63
nm
1308.09 to 1310.19
nm
G0365A
100G LR4
Dual Rate
1310 nm QSFP28
100G
Ethernet/OTN
Single mode
1310 nm (10 km)
-8.4 dBm
per Lane
1294.53 to 1296.59
nm
1299.02 to 1301.09
nm
1303.54 to 1305.63
nm
1308.09 to 1310.19
nm
Total: 10.0 dBm
max.
-0.6 to 4.0 dBm
per Lane
1294.53 to 1296.59
nm
1299.02 to 1301.09
nm
1303.54 to 1305.63
nm
1308.09 to 1310.19
nm
G0366A
100G
850 nm QSFP28
100G Ethernet
Multi mode
850 nm (0.1 km)
-9.9 dBm
per Lane
840 to 860 nm
Total: 8.9 dBm
max.
-9.1 to 2.4 dBm
per Lane
840 to 860 nm
G0369A
100G LR4
Dual Rate
1310 nm CFP4
100G
Ethernet/OTN
Single mode
1310 nm (10 km)
-8.6 dBm
per Lane
1294.53 to 1296.59
nm
1299.02 to 1301.09
nm
1303.54 to 1305.63
nm
1308.09 to 1310.19
nm
Total: 10.5 dBm
max.
-4.3 to 4.5 dBm
per Lane
1294.53 to 1296.59
nm
1299.02 to 1301.09
nm
1303.54 to 1305.63
nm
1308.09 to 1310.19
nm
