Chapter 6. System Status
249
Item Description
Basic Device Name: Enter a name for the Receiver.
Description: Enter a description for the Receiver.
Location: Use the drop-down menu to select a Location for the
device. Locations help organize how you view Receivers on the
settings page.
Mode: Use the radio button to select how the Receivers will be
installed and managed:
Select Extender mode for simple one-to-one (Transmitter to
Receiver) setups that are managed with the Receiver’s OSD
menu.
Select Matrix mode to manage devices and connections over
the LAN from the KVM over IP Matrix Manager. This mode is for
advanced administration of Transmitter and Receiver
connections configured within the KVM over IP Matrix Manager
Web GUI.
Enable Media: Select which source type the Receiver can stream:
Video, Audio, USB and RS232.
Audio Output: Use this option to independently stream HDMI,
Analog, or Both audio signals to digital or analog audio output
devices (speakers) connected to the Receiver.*
CCKM IP: Set the IP address and Port number of the computer
running the KVM over IP Matrix Manager. The default port number
is 9110.
IP Installer: The IP Installer is an external Windows-based utility
for assigning an IP address to the device. Click a radio button to
select Enable, Disable or View Only for the IP Installer utility.
See IP Installer, page 420 for instructions.
RS232 Settings Configure the serial device settings for the Transmitter. The default
settings are:
Baud Rate: 9600
Parity: None
Data Bits: 8 bits
Stop bits: 1 bit
Flow Control: None
Extender
Properties
If you selected Extender mode (under Basic) set the Transmitter IP
address for the Receiver’s Video, Audio, USB, and RS232 source.
If you selected Matrix mode (under Basic) the Properties will be
grayed out. Use Transmitters, Virtual Transmitters, and Transmitter
Groups to configure the connections (see Transmitter, page 226).
