KVM over IP Matrix System User Manual
18
8 console ports The unit’s USB keyboard and USB mouse plug into these
ports.
Note: When using a keyboard or mouse with special
functions, see USB Mode, page 250.
9 LAN port The cable that connects the unit to the LAN plugs in here.
10 DVI-I output The cable from the local DVI monitor plugs in here.
No. Component Description
