MP-202 Telephone Adapter 154 Document #: LTRT-50605
User's Manual
8. Under the screen section 'QoS Operation', set rule priority with Quality of Service by
checking the check box (to add a priority to the rule); the screen refreshes (refer to the
figure), allowing you to select between one of eight priority levels, zero being the
lowest and seven the highest (each priority level is mapped to low/medium/high
priority). This sets the priority of a packet on the connection matching the rule, while
routing the packet.
Figure 12-27: Set Priority Rule
9. Check the check box 'Set DSCP' to mark a DSCP value on packets matching this rule;
the screen refreshes (refer to the figure), allowing you to enter the hexadecimal value
of the DSCP.
Figure 12-28: Set DSCP Rule
10. Under the screen section 'Logging', check the parameter 'Log Packets Matched by
This Rule' to log the first packet from a connection that was matched by this rule.
11. By default, the 'Schedule' rule will always be active. However, you can configure
scheduler rules in order to define time segments during which the rule may be active.
12. Click 'OK' to save the settings.
