AudioCodes MP-202 User Manual

MP-202 Telephone Adapter 194 Document #: LTRT-50605
User's Manual
¾ To configure a DHCP relay server:
1. From the 'IP Address Distribution' drop-down list, select 'DHCP Relay'; the screen
'DHCP Relay Server Address' opens (refer to the figure below). Use this screen to
configure your DHCP server's IP address.
Figure 13-33: DHCP Server Relay
2. Click 'OK' to save your changes.
13.19.2 DHCP Relay Parameters
To configure a device as a DHCP relay, perform the following steps:
1. Select the 'DHCP Relay' option in the 'IP Address Distribution' drop-down list under
the screen section 'Service' (refer to the figure).
Figure 13-34: Advanced - IP Address Distribution - DHCP Relay
2. Click the link 'New IP Address'; the 'DHCP Relay Server Address' screen opens (refer
to the figure).
Figure 13-35: Advanced - IP Address Distribution - DHCP Relay - New IP Address
3. Specify the IP address of the DHCP server.

AudioCodes MP-202 Specifications

General

Model	MP-202
Category	Adapter
Ports	2 FXS ports
Protocol Support	SIP, H.323
Weight	0.5 kg
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% non-condensing
Network Interface	10/100Base-T Ethernet
Voice Codecs	G.711, G.729, G.723.1, G.726
Security	HTTPS, TLS, SRTP
Management	Web-based, SNMP
Power Supply	12V DC
