MP-202 Telephone Adapter 48 Document #: LTRT-50605
User's Manual
Table 5-14: VoIP - Services
Parameter Description
Call Waiting
Call Waiting SIP Reply - Which response message is sent when another
call arrives while a call is in progress. There are two possibilities: 180
Ringing or 182 Queued (default). To disable the call waiting feature, select
180 Ringing.
Call Forward Type
The Call Forward feature permits a user to redirect incoming calls
addressed to him/her to another number. The user’s ability to originate calls
is unaffected by Call Forward. Three types of Call Forwarding exist:
Unconditional. When selected, incoming calls are forwarded
independently of the status of the endpoint.
Busy. When selected, incoming calls are forwarded only if the endpoint
is busy, i.e., if all lines are active.
No Reply. When selected, incoming calls are forwarded only if the
endpoint does not answer before a pre-configured timeout (see next
parameter).
Time for No Reply
Forward
If you specify 5 seconds for this parameter, for example, and 'No Reply' is
selected for parameter 'Call Forward Type' (see above), incoming calls are
forwarded only after 5 seconds lapse.
Key Sequence
The default is *72 but users can modify to any sequence of up to 2 digits,
i.e., *n or *nm.
3 Way Conference
Mode
Selects how 3-way conference calls are handled - locally by the device or
by a remote media server (RFC 4240).
Media Server Address*
The address of the remote media server that handles conference calls.
Message Waiting
Indication
If a user has an unheard voice mail message, a stutter dial tone is heard
when the user picks up the phone. In addition, the MP 202 generates an
FSK signal to the phone to indicate that a message is waiting. If the
telephone connected to the MP-202 supports this feature, an MWI
‘envelope icon’ is displayed.
Subscribe to MWI
Check this checkbox if you must register with a MWI subscriber server. If
so, configure the three parameters below.
MWI Server IP Address
or Host Name
The IP address or host name of the MWI server.
MWI Server Port
The port number of the MWI server.
MWI Subscribe
Expiration TIme
The interval between registrations.
Stutter Tone Duration
When you enable message waiting and an unheard message exists, you'll
hear a stutter tone for the duration configured in this parameter and/or when
you activate the call forwarding feature (refer to ''Forwarding Calls to
Another Phone'' on page 59)
Out of Service Behavior
Defines the tone which is played instead of a dial tone if the user configured
a registrar IP and the registration failed. When the Reorder tone is selected,
a Reorder tone is played instead of a dial tone. If “No Tone” is selected, then
no tone is played.
* This parameter appears only if '3 Way Conference Mode' is remote server.
