AudioCodes MP-202 - Figure 5-3: Voip - Signaling Protocol - SIP Proxy and Registrar; Table 5-5: Voip - Signaling Protocol - SIP Registrar SIP

MP-202 Telephone Adapter 36 Document #: LTRT-50605
User's Manual
 Uncheck the box 'Use SIP Proxy IP and Port for Registration' and check 'Use SIP
Registrar'; the parameters screen for 'SIP Registrar' opens (showing the basic
parameters).
Figure 5-3: VoIP - Signaling Protocol - SIP Proxy and Registrar
The table below shows descriptions of those SIP Registrar parameters that differ from SIP
Proxy parameters. Descriptions of common parameters can be seen under the section 'SIP
Proxy and Registrar', above.
Table 5-5: VoIP - Signaling Protocol - SIP Registrar SIP
Parameter Description
Use SIP Registrar
Check the box to use a separate SIP registrar server.
Registrar Address
The IP address or host name of the registrar server.
Registrar Port
The UDP or TCP port of the registrar server.
Registrar Expires
The registration timeout, in seconds.
