AutomationDirect CLICK Series User Manual

GettinG Started
1
1
1
Chapter
Chapter
Chapter
In This Chapter...
Introduction .............................................................................................................. 1–2
Conventions Used ..................................................................................................... 1–3
Before you begin... ................................................................................................... 1–4
Step 1: Install Programming Software..................................................................... 1–5
Step 2: Launch Programming Software ................................................................... 1–6
Step 3: Create a Project ............................................................................................ 1–8
Step 4: Compile and Save Project .......................................................................... 1–14
Step 5: Apply Power ............................................................................................... 1–15
Step 6: Establish PC to PLC Communications........................................................ 1–16
Step 7: Write Project into PLC ............................................................................... 1–24
Step 8: Place PLC in RUN Mode ............................................................................. 1–25
Step 9: Test Project using Data View Monitor ...................................................... 1–26
Step 10: Y001 Output On? ..................................................................................... 1–27
Additional Training Resources ................................................................................ 1–28
